Westinghouse Lighting - Lamp Catalog

16 / 84

LED LAMPS
14
3 Low Voltage (12V)
4 Approved for Damp Location
Footnotes
1 New Item
2 Dimmable
5 Approved for Wet Location
6 Indoor Application Only
7 Approved for Use in Totally Enclosed Fixtures
GENERAL
PURPOSE LAMPS
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inne Pack
Package
Type
Equiv.
Incand.
Wattage
Color
Designation Finish
Light
Appearance
(Kelvin) CRI
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.Yearly
Energy
Cost** MOL
OMNI A15
5 Med. 45134 4,7 5OMNIA15/LED/SW/27 1CD 24/4 Card 40 Warm White Soft White 2700 80 450 15000 13.6 $0.60 3.54"
5.5 Med. 45136 4,7 5.5OMNIA15/LED/SW/27 1CD 24/4 Card 60 Warm White Soft White 2700 80 600 15000 13.6 $0.66 3.55"
Med. 33191 2,4,7 5.5OMNIA15/LED/DIM/SW/27 1CD 24/4 Card 40 Warm White Soft White 2700 80 450 25000 22.8 $0.66 3.54"
A19
14 Med. 53798 4,7 14A19/LED/SW/30 24/6 Box 100 Warm White Soft White 3000 80 1500 15000 13.6 $1.69 4.21"
Med. 45158 4,7 14A19/LED/SW/30 2PK 60/12 Box (2) 100 Warm White Soft White 3000 80 1500 15000 13.6 $1.69 4.21"
Med. 55142 4,7 14A19/LED/SW/50 24/6 Box 100 Daylight Soft White 5000 80 1500 15000 13.6 $1.69 4.21"
OMNI A19
6 Med. 43464 4,7 6OMNIA19/LED/SW/27 24/6 Box 40 Warm White Soft White 2700 80 480 25000 22.8 $0.72 4.33"
Med. 43189 4,7 6OMNIA19/LED/SW/30 24/6 Box 40 Warm White Soft White 3000 80 480 15000 13.6 $0.72 4.33"
Med. 35156 4,7 6OMNIA19/LED/SW/30 4PK 30/6 Box (4) 40 Warm White Soft White 3000 80 480 15000 13.6 $0.72 4.33"
Med. 35138 4,7 6OMNIA19/LED/SW/50 24/6 Box 40 Daylight Soft White 5000 80 480 15000 13.6 $0.72 4.33"
6.5 Med. 50730 1,2,4,7 6.5OMNIA19/LED/DIM/SW/30 24/6 Box 40 Warm White Soft White 3000 90 470 25000 22.8 $0.78 4.25"
9 Med. 03697 4,7 9OMNIA19/LED/SW/27 24/6 Box 60 Warm White Soft White 2700 80 790 40000 36.5 $1.08 4.33"
Med. 43697 4,7 9OMNIA19/LED/SW/27 24/6 Box 60 Warm White Soft White 2700 80 800 25000 22.8 $1.08 4.33"
Med. 05173 4,7 9OMNIA19/LED/SW/27 12PK 2 Box (12) 60 Warm White Soft White 2700 80 800 15000 13.6 $1.08 4.33"
Med. 03440 4,7 9OMNIA19/LED/SW/30 1CD 24/6 Card 60 Warm White Soft White 3000 80 800 40000 36.5 $1.08 4.33"
Med. 43440 4,7 9OMNIA19/LED/SW/30 1CD 24/4 Card 60 Warm White Soft White 3000 80 800 25000 22.8 $1.08 4.33"
Med. 43127 4,7 9OMNIA19/LED/SW/30 24/6 Box 60 Warm White Soft White 3000 80 800 15000 13.6 $1.08 4.33"
Med. 35160 4,7 9OMNIA19/LED/SW/30 4PK 30/6 Box (4) 60 Warm White Soft White 3000 80 800 15000 13.6 $1.08 4.33"
Med. 35140 4,7 9OMNIA19/LED/SW/50 24/6 Box 60 Daylight Soft White 5000 80 800 15000 13.6 $1.08 4.33"
9.8 Med. 50770 1,2,4,7 9.8OMNIA19/LED/DIM/SW/40 24/6 Box 60 Cool White Soft White 4000 80 800 25000 22.8 $1.18 4.33"
10 Med. 03696 2,4,7 10OMNIA19/LED/DIM/SW/27 24/6 Box 60 Warm White Soft White 2700 80 790 40000 36.5 $1.20 4.33"
Med. 50720 1,2,4,7 10OMNIA19/LED/DIM/SW/27 24/6 Box 60 Warm White Soft White 2700 90 800 25000 22.8 $1.20 4.25"
Med. 03439 2,4,7 10OMNIA19/LED/DIM/SW/30 1CD 24/6 Card 60 Warm White Soft White 3000 80 800 40000 36.5 $1.20 4.33"
Med. 50740 1,2,4,7 10OMNIA19/LED/DIM/SW/30 24/6 Box 60 Warm White Soft White 3000 90 800 25000 22.8 $1.20 4.25"
Med. 50780 1,4,7 10OMNIA19/LED/SW/40 24/6 Box 60 Cool White Soft White 4000 80 800 15000 13.6 $1.20 4.33"
11 Med. 53190 4,7 11OMNIA19/LED/SW/30 24/6 Box 75 Warm White Soft White 3000 80 1100 15000 13.6 $1.32 4.49"
Med. 50810 2,4,7 11OMNIA19/LED/DIM/SW/30 24/6 Box 75 Warm White Soft White 3000 80 1100 25000 22.8 $1.32 4.49"
Med. 45157 4,7 11OMNIA19/LED/SW/30 2PK 60/12 Box (2) 75 Warm White Soft White 3000 80 1100 15000 13.6 $1.32 4.49"
Med. 45141 4,7 11OMNIA19/LED/SW/50 24/6 Box 75 Daylight Soft White 5000 80 1100 15000 13.6 $1.32 4.49"
Med. 45145 2,4,7 11OMNIA19/LED/DIM/SW/50 24/6 Box 75 Daylight Soft White 5000 80 1100 25000 22.8 $1.32 4.49"
15 Med. 50940 2,4,7 15OMNIA19/LED/DIM/SW/27 24/6 Box 100 Warm White Soft White 2700 80 1600 25000 22.8 $1.81 4.92"
Med. 50750 1,2,4,7 15OMNIA19/LED/DIM/SW/40 24/6 Box 100 Cool White Soft White 4000 80 1600 25000 22.8 $1.81 4.64"
15.5 Med. 50760 1,4,7 15.5OMNIA19/LED/SW/40 24/6 Box 100 Cool White Soft White 4000 80 1600 15000 13.6 $1.87 4.64"
Med. 50790 1,4,7 15.5OMNIA19/LED/SW/50 24/6 Box 100 Daylight Soft White 5000 80 1600 15000 13.6 $1.87 4.64"
3/9/12 Med. 53140 4 3/9/12OMNIA19/LED/3WAY/SW/27 24/6 Box
30/
70/
100
Warm White Soft White 2700 80
280/
950/
1200
25000 22.8 $1.45 4.65"
*Based on 3hrs./day **Based on 3hrs./day 11¢/kWh
A19 OMNI A15
SOFTWHITE/CLEAR
OMNI A19
SOFTWHITE
2016TITLE24 CANBEUSEDTOCOMPLYWITH
PART6
HIGHEFFICACYLEDLIGHTSOURCEREQUIREMENTS
2016TITLE24
CANBEUSEDTOCOMPLYWITH
PART6
HIGHEFFICACYLEDLIGHT
SOURCEREQUIREMENTS
2016TITLE24 CANBEUSEDTOCOMPLYWITH
PART6
HIGHEFFICACYLEDLIGHTSOURCEREQUIREMENTS
2016TITLE24 CANBEUSEDTOCOMPLYWITH
PART6
HIGHEFFICACYLEDLIGHT
SOURCEREQUIREMENTS These lamps can be used to comply with the 2016 Title 24, Part 6, high efficacy light source requirements in the state of California.
