HALOGEN LAMPS
62
www.westinghouselighting.comFILAMENT
SUPPORTS
SEAL
FILAMENT
BULB
(ENVELOPE)
FILLING TIP
CONTACT
MOLYBDENUM
FOIL
BASE
A variety of bases are
used in halogen lamps.
(pictured is a ceramic RSC base halogen)
130V LAMP SPECIFICATIONS — OPERATING ON A 130V LINE
OPERATING ON A 120V LINE
Item
No.
Energy
Used
(Watts)
Domestic Code
Master Carton/
Inner Pack
Avg.
Rated
Hours
Brightness
(Lumens)
Energy Used
(Watts)
@ 120V
Avg. Rated
Hours
@ 120V
Brightness
(Lumens)
@ 120V
04764
75
75T4Q/GY8/130
36/6
2000
975
66
5600
731
04770
100 100T4Q/GY8/130
36/6
2000
1400
88
5600
1050
04783
150 150T3Q/RS/130
36/6
1500
2600
132
4200
1950
04784
150 150T3Q/RS/130
36/6
1500
2400
132
4200
1800
04786
300 300T3Q/RS/130
36/6
1500
5000
264
4200
3750
04788
500 500T3Q/RS/130
36/6
1500
9500
440
4200
7125
04829
500 500T3Q/130
100/10
1500
10500
440
4200
7875
04979
300 300T3Q/RS/130 2CD
36/6
4000
4000
264
11200
3000
04981
500 500T3Q/RS/130 2CD
36/6
4000
8000
440
11200
6000
130 Volt lamps will last longer when used on a 120 Volt line. However, the brightness (lumen output) of these
130 Volt lamps operating on a 120 Volt line will be significantly reduced, while energy consumption (watts) will be less.
A 130 Volt lamp is perfect for use in hard-to-reach places and for use in lights that are on for long periods of time. Westinghouse Lighting
recommends that you check that there is enough brightness (lumen output) for your specific application or task.
XENON LAMPS
Xenon lamps are incandescent lamps filled with Xenon
and other gases. Xenon lamps in comparison to their
standard incandescent and halogen lamp counterparts
are more efficient, have longer life and have a crisper,
brighter light output. All Xenon lamps provide instant
brightness and are fully dimmable.
ECO-HALOGEN LAMPS
Eco-Halogen lamps utilize an improved halogen burner
that makes them more efficient than a standard halogen
equivalent lamp. Additionally Eco-PAR PLUS Halogen
lamps utilize an advanced reflective technology to deliver
extended life. All Eco-Halogen lamps provide instant
brightness and are fully dimmable, plus offer energy
savings that meet federal energy efficient standards.
130 VOLT COMPARISON CHART
HALOGEN LAMP COMPONENTS
NOTE:
Most electrical service is 120 Volts. By using 130 Volt lamps on a 120 Volt line, replacement and maintenance costs can be reduced due to longer life.
