Westinghouse Lighting Catalog - Light Fixtures, Ceiling Fans & Accessories

12 / 132

Item No.
Number
of Lamps
Energy Used
(Watts)†
Equiv. Incand.
Wattage†
Light Appearance
(Kelvin) Lumens† CRI
Average
Rated Hours
Life
in Years*
Est. Yearly
Energy Cost**†
63624 ✶ 8 40 3000 (WarmWhite) 560 80 25000 22.8 $0.96
63625 ✶ 8 40 3000 (WarmWhite) 560 80 25000 22.8 $0.96
63626 ✶ 8 40 3000 (WarmWhite) 540 80 25000 22.8 $0.96
63504 4 4.5 60 2700 (WarmWhite) 450 80 15000 13.6 $0.54
63296 ✶ 7.5 40 3000 (WarmWhite) 170 80 40000 36.5 $0.90
63297 ✶ 7.5 40 3000 (WarmWhite) 260 80 40000 36.5 $0.90
63553 ✶ 8 40 3000 (WarmWhite) 450 80 25000 22.8 $0.96
63554 ✶ 8 40 3000 (WarmWhite) 450 80 25000 22.8 $0.96
63079 ✶ 8 40 3000 (WarmWhite) 450 80 25000 22.8 $0.96
For a complete list of compatible dimmers, visit *Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
† Values are per lamp. ✶Integrated LED Light Source
LED LIGHT SOURCE SPECIFICATIONS
INDOOR HANGING
10
1 Light LED Mini Pendant
63553 Cava
Champagne Brass Finish with Bubble Glass
Height: 61.05" Diameter: 4.96"
Adjustable Cord: 50"
Includes 8 Watt Integrated LED
1 Light LED Mini Pendant
63554 Cava
Gun Metal Finish with Bubble Glass
Height: 61.05" Diameter: 4.96"
Adjustable Cord: 50"
Includes 8 Watt Integrated LED
1 Light LED Mini Pendant
63079 Cava
Chrome Finish with Bubble Glass
Height: 61.05" Diameter: 4.96"
Adjustable Cord: 50"
Includes 8 Watt Integrated LED
4 Light LED Pendant
63504 Skybridge
Iron Finish
Height: 35.24" Square: 11.81"
Includes (4) Medium (E26) Base Lamps,
4.5 Watt T9 Filament LED (WL Lamp #35184)
Includes (2) 9.5" and (2) 4.75" long rods
1 Light LED Mini Pendant
63296
Matte Brushed Gun Metal Finish with Metal Shade
Height: 65.63" Diameter: 5.00"
Adjustable Cord: 50"
Includes 7.5 Watt Integrated LED
1 Light LED Mini Pendant
63297
Brushed Nickel Finish with Frosted Opal Glass
Height: 71.54" Diameter: 6.70"
Adjustable Cord: 50"
Includes 7.5 Watt Integrated LED
1 Light LED Pendant
63624
White Finish
Height: 58.11" Diameter: 13.78"
Adjustable Cord: 50"
Includes 8 Watt Integrated LED
1 Light LED Pendant
63625
Brushed Nickel Finish
Height: 58.11" Diameter: 13.78"
Adjustable Cord: 50"
Includes 8 Watt Integrated LED
1 Light LED Pendant
63626
Copper Finish
Height: 54.80" Diameter: 13.98"
Adjustable Cord: 50"
Includes 8 Watt Integrated LED
INDOOR HANGING LIGHT FIXTURES
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
•
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
• Hand Blown Glass
DIMMABLE
New!
New! New! New!
New! New! FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
