Westinghouse Lighting Catalog - Light Fixtures, Ceiling Fans & Accessories

41 / 132

• Hand Blown Glass
* Fixture can be installed up or down
INDOOR WALL
39
2 Light Wall
63039 Alexander
Brushed Nickel Finish
with Rippled White Glazed Glass
Height: 11.14" Width: 15.24" Extends: 5.90"
Use (2) Medium (E26) Base Lamps, 60 Watt Maximum
3 Light Wall
63040 Alexander
Brushed Nickel Finish
with Rippled White Glazed Glass
Height: 11.14" Width: 22.50" Extends: 5.90"
Use (3) Medium (E26) Base Lamps, 60 Watt Maximum
4 Light Wall
63041 Alexander
Brushed Nickel Finish
with Rippled White Glazed Glass
Height: 11.14" Width: 30.24" Extends: 5.90"
Use (4) Medium (E26) Base Lamps, 60 Watt Maximum
3 Light LED Wall
63295 Blake
Chrome Finish with Glazed Ice Cylinder Glass
Height: 7.64" Width: 15.16" Extends: 5.16"
Includes 3 x 6.67 Watt Integrated LEDs
3 Light LED Wall
63299 Cava II
Brushed Nickel Finish with Bubble Glass
Height: 5.51" Width: 19.69" Extends: 2.89"
Includes 3 x 6.33 Watt Integrated LEDs
3 Light LED Wall
63300 Zaya
Brushed Nickel Finish with Sparkle Glass
Height: 6.63" Width: 21.26" Extends: 5.71"
Includes 3 x 9.67 Watt Integrated LEDs
1 Light LED Wall
63076 Cava
Chrome Finish with Bubble Glass, Dimmable
Height: 7.76" Width: 4.96" Extends: 5.69"
Includes 8 Watt Integrated LED
2 Light LED Wall
63077 Cava
Chrome Finish with Bubble Glass, Dimmable
Height: 7.76" Width: 9.46" Extends: 5.69"
Includes 2 x 7.5 Watt Integrated LEDs
3 Light LED Wall
63119 Cava
Chrome Finish with Bubble Glass
Height: 7.76" Width: 15.16" Extends: 5.69"
Includes 3 x 7.33 Watt Integrated LEDs
Item No.
Number
of Lamps
Energy Used
(Watts)
Equiv. Incand.
Wattage
Light Appearance
(Kelvin) Lumens CRI
Average
Rated Hours
Life
in Years*
Est. Yearly
Energy Cost**
63076 ✶ 8 40 3000 (WarmWhite) 400 80 25000 22.8 $0.96
63077 ✶ 15 80 3000 (WarmWhite) 900 80 25000 22.8 $1.81
63119 ✶ 22 120 3000 (WarmWhite) 1300 80 25000 22.8 $2.65
63295 ✶ 21 120 3000 (WarmWhite) 1500 80 40000 36.5 $2.53
63299 ✶ 21 120 3000 (WarmWhite) 1520 80 40000 36.5 $2.53
63300 ✶ 30 180 3000 (WarmWhite) 2400 80 40000 36.5 $3.61
For a complete list of compatible dimmers, visit *Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
✶ Integrated LED Light Source
LED LIGHT SOURCE SPECIFICATIONS
• * • * • *
* *
• * *
INTEGRATED
DIMMABLE
COMPLIANT
ADA
*
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
FIXTURE
FAMILY
COORDINATING
ITEMSAVAILABLE
*
