61 / 132
www.westinghouselighting.com
Item No.
Number
of Lamps
Energy Used
(Watts)
Equiv. Incand.
Wattage
Light Appearance
(Kelvin)
Lumens
CRI
Average
Rated Hours
Life
in Years*
Est. Yearly
Energy Cost**
63613
✶
8.5
40
2700 (WarmWhite)
428
80
20000
18.2
$1.02
63614
✶
17
120
2700 (WarmWhite)
909
80
20000
18.2
$2.05
63156
✶
8.5
40
2700 (WarmWhite)
428
80
20000
18.2
$1.02
63157
✶
17
120
2700 (WarmWhite)
909
80
20000
18.2
$2.05
For a complete list of compatible dimmers, visit
www.westinghouselighting.com.*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
✶
Integrated LED Light Source
LED LIGHT SOURCE SPECIFICATIONS
OUTDOOR FIXTURES
59
1 Light Wall Fixture
63609
Watts Creek
Galvanized Steel Finish
Height: 11.02" Width: 11.00" Extends: 12.60"
Height from Center of Outlet Box: 6.14"
Back Plate: D: 5.71"
Use (1) Medium (E26) Base Lamp, 60 Watt Maximum
1 Light Wall Fixture
62044
Watts Creek
Textured Black Finish
Height: 11.02" Width: 11.00" Extends: 12.60"
Height from Center of Outlet Box: 6.14"
Back Plate: D: 5.71"
Use (1) Medium (E26) Base Lamp, 60 Watt Maximum
1 Light Wall Fixture
63608
Watts Creek
Textured Black Finish
Height: 14.84" Width: 14.96" Extends: 16.97"
Height from Center of Outlet Box: 8.27"
Back Plate: D: 6.69"
Use (1) Medium (E26) Base Lamp, 60 Watt Maximum
1 Light Wall Fixture
67973
Polished Graphite Finish
Height: 7.00" Width: 4.50" Extends: 7.87"
Height from Center of Outlet Box: 2.76"
Back Plate: H: 5.00" W: 4.25"
Use (1) Medium (E26) Base Lamp, 75 Watt Maximum
2 Light Wall Fixture
with Up and Down Light
67975
Polished Graphite Finish
Height: 15.00" Width: 5.00" Extends: 8.25"
Height from Center of Outlet Box: 7.50"
Back Plate: H: 5.00" W: 4.25"
Use (2) Medium (E26) Base Lamps, 75 Watt Maximum
1 Light LED Wall Fixture
63156
Mayslick
Oil Rubbed Bronze Finish with Frosted Glass Panel
Height: 7.09" Width: 5.00" Extends: 5.12"
Height from Center of Outlet Box: 3.54"
Back Plate: H: 5.00" W: 5.00"
Includes 8.5 Watt Integrated LED
2 Light LED Wall Fixture
with Up and Down Light
63157
Mayslick
Oil Rubbed Bronze Finish with Frosted Glass Panels
Height: 12.20" Width: 5.00" Extends: 5.12"
Height from Center of Outlet Box: 6.10"
Back Plate: H: 5.00" W: 5.00"
Includes 2 x 8.5 Watt Integrated LEDs
1 Light LED Wall Fixture
63613
Mayslick
White Finish with Frosted Glass Lens
Height: 7.09" Width: 5.00" Extends: 5.12"
Height from Center of Outlet Box: 3.54"
Back Plate: H: 5.00" W: 5.00"
Includes 8.5 Watt Integrated LED
2 Light LED Wall Fixture
with Up and Down Light
63614
Mayslick
White Finish with Frosted Glass Panels
Height: 12.20" Width: 5.00" Extends: 5.12"
Height from Center of Outlet Box: 6.10"
Back Plate: H: 5.00" W: 5.00"
Includes 2 x 8.5 Watt Integrated LEDs
INTEGRATED
DIMMABLE
INTEGRATED
DIMMABLE
INTEGRATED
New!
New!
New!
New!
FRIENDLY
DARK
SKY
FRIENDLY
DARK
SKY
FRIENDLY
DARK
SKY
FRIENDLY
DARK
SKY
FRIENDLY
DARK
SKY
FRIENDLY
DARK
SKY
INTEGRATED
All outdoor fixtures in this section
are wet rated unless otherwise noted.
INDOOR
OUTDOOR
WET RATED
