LED LAMPS
14
3 Low Voltage (12V)
4 Approved for Damp Location
Footnotes
1 New Item
2 Dimmable
5 Approved for Wet Location
6 Indoor Application Only
7 Approved for Use in Totally Enclosed Fixtures
JCD
G8 BASE
HALOGEN ALTERNATIVE
SPECIALTY LAMPS
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Package
Type
Equiv.
Halogen
Wattage
Color
Designation Finish
Light
Appearance
(Kelvin) CRI
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
JC
1.5 G4 33184 3,4,7 1.5G4/LED/F/30 1CD 24/4 Card 10 Warm White Frost 3000 80 120 25000 22.8 $0.18 1.46"
3 G4 51610 1,3,4,7 3G4/LED/CL/30 100/10 Box 20 Warm White Clear 3000 80 300 25000 22.8 $0.36 1.69"
3.5 GY6.35 51660 1,2,4,7 3.5GY6.35/LED/DIM/CL/30 100/10 Box 35 Warm White Clear 3000 80 300 25000 22.8 $0.42 1.46"
JCD
2.5 G9 03185 4,7 2.5G9/LED/F/30 1CD 24/4 Card 25 Warm White Frost 3000 80 220 25000 22.8 $0.30 2.05"
4.5 G8 51650 1,2,4,7 4.5G8/LED/DIM/CL/30 100/10 Box 35 Warm White Clear 3000 80 380 25000 22.8 $0.54 1.85"
5 G9 51640 1,2,4,7 5G9/LED/DIM/CL/30 100/10 Box 40 Warm White Clear 3000 80 480 25000 22.8 $0.60 2.13"
DOUBLE-ENDED SHORT
5 RSC 33186 4,7 5R7S/LED/CL/27 1CD 24/4 Card 40 Warm White Clear 2700 80 550 25000 22.8 $0.60 3.07"
DOUBLE-ENDED LONG
9 RSC 03187 4,7 9R7S/LED/CL/27 1CD 24/4 Card 75 Warm White Clear 2700 80 900 25000 22.8 $1.08 4.65"
SINGLE-ENDED
5 BA15D 51620 1,2,4,7 5BA15D/LED/DIM/CL/30 100/10 Box 50 Warm White Clear 3000 80 500 25000 22.8 $0.60 2.44"
E11 51630 1,2,4,7 5E11/LED/DIM/CL/30 100/10 Box 50 Warm White Clear 3000 80 500 25000 22.8 $0.60 2.24"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
Replacements for 13W, 18W, 32W and 42W CFL pin base lamps.
PIN BASE LAMPS
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Package
Type
Equiv.
Halogen
Wattage
Color
Designation Finish
Light
Appearance
(Kelvin) CRI
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
HORIZONTAL INSTALLATION
9 G24Q GX24Q 51470 ◗ 1,2,4,7 9PL/H/LED/DIM/G24Q/30 24/6 Box 26 Warm White White 3000 82 900 50000 45.6 $1.08 5.20"
G24Q GX24Q 51480 ◗ 1,2,4,7 9PL/H/LED/DIM/G24Q/35 24/6 Box 26 Warm White White 3500 82 950 50000 45.6 $1.08 5.20"
G24Q GX24Q 51490 ◗ 1,2,4,7 9PL/H/LED/DIM/G24Q/40 24/6 Box 26 Cool White White 4000 82 1000 50000 45.6 $1.08 5.20"
VERTICAL INSTALLATION
9 G24Q GX24Q 51500 ◗ 1,2,4,7 9PL/V/LED/DIM/G24Q/30 24/6 Box 26 Warm White White 3000 82 950 50000 45.6 $1.08 4.65"
G24Q GX24Q 51510 ◗ 1,2,4,7 9PL/V/LED/DIM/G24Q/35 24/6 Box 26 Warm White White 3500 82 1000 50000 45.6 $1.08 4.65"
G24Q GX24Q 51520 ◗ 1,2,4,7 9PL/V/LED/DIM/G24Q/40 24/6 Box 26 Cool White White 4000 82 1050 50000 45.6 $1.08 4.65"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
HORIZONTAL PL VERTICAL PL
JC
G4 BASE
JCD
G9 BASE
5WDOUBLE-ENDED SHORT
9WDOUBLE-ENDED LONG
JC
GY6.35 BASE
SINGLE-ENDED
BA15D BASE
SINGLE-ENDED
E11 BASE
See individual product specification sheets for dimmer and ballast compatibility on www.westinghouselighting. com.
◗ Dimmable when used with a compatible dimming ballast.
JCD
G9 BASE
