Westinghouse Lighting - Lamp Catalog

22 / 52

HALOGEN LAMPS
20
ECO-HALOGEN &
SPECIALTY HALOGEN LIGHTING
Providing bright, white light and long life, our halogen lamps come in a variety of
sizes and shapes. These lamps are completely dimmable and can be used anywhere,
making them an excellent choice for multiple lighting solutions.
5 Rough Service
6 Canadian Standards Association
1 New Item
2 Clear Lens
3 Frost Lens
4 Eco-Halogen Energy-Saving Technology
Footnotes
7 Krypton(K) / Xenon(X)
8 Long Neck
MR11 GU10 BASE
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Avg.
Rated
Hours
ANSI
Code
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
MR11 120 VOLT
35 GU10 04728 2 35MR11Q/GU10/NFL/LN 3CD 36/6 Card (3) 500 30° Narrow Flood CC2V 3000 3000 FTH 2.7 $4.22 1.86"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
MR11 LAMP, 120 VOLT DICHROIC (LINE VOLTAGE)
MR16 CLEAR LENS
GU5.3 BASE
MR16
GU5.3 BASE
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Avg.
Rated
Hours
ANSI
Code
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
MR16 12 VOLT
20 GU5.3 04781 2 20MR16Q/FL/LN 36/6 Card 600 32° Flood C8 2950 2000 BAB 1.8 $2.41 1.81"
GU5.3 06212 2,7 20MR16X/FL/LN 2CD 36/6 Card (2) 700 32° Flood C8 2950 10000 BAB 9.1 $2.41 1.81"
GU5.3 04749 2 20MR16Q/SP/LN 36/6 Card 3500 12° Spot C8 2950 2000 ESX 1.8 $2.41 1.81"
35 GU5.3 04563 2 35MR16Q/FL/LN 36/6 Card 1250 32° Flood C8 3000 2000 FMW 1.8 $4.22 1.81"
50 GU5.3 04755 2 50MR16Q/NFL/LN 36/6 Card 4300 18° Narrow Flood C6 3050 2000 EXZ 1.8 $6.02 1.81"
GU5.3 04456 50MR16Q/FL 100/10 Box 1500 38 Flood C8 3050 2000 EXN 1.8 $6.02 1.81"
GU5.3 04586 50MR16Q/FL 100/10 Box 2000 38° Flood C8 3000 5000 EXN 4.5 $6.02 1.88"
GU5.3 04756 2 50MR16Q/FL/LN 36/6 Card 1650 32° Flood C8 3050 2000 EXN 1.8 $6.02 1.81"
GU5.3 06213 2,7 50MR16X/FL/LN 2CD 36/6 Card (2) 1500 32° Flood C8 3050 10000 EXN 9.1 $6.02 1.81"
GU5.3 04559 2 50MR16Q/SP/LN 36/6 Card 10000 12° Spot C8 3050 2000 EXT 1.8 $6.02 1.81"
75 GU5.3 04758 2 75MR16Q/FL/LN 36/6 Card 2940 32° Flood C8 3050 2000 EYC 1.8 $9.03 1.81"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
MR16 LAMPS, 12 VOLT DICHROIC (LOW VOLTAGE)
MR11 LAMPS, DICHROIC (LOW VOLTAGE) MR11 GU4 BASE
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Avg.
Rated
Hours
ANSI
Code
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
6 VOLT
5 GU4 04771 2 5MR11Q/NFL/LN 36/6 Card 200 16° Narrow Flood C8 2900 2000 - 1.8 $0.60 1.38"
12 VOLT
5 GU4 04766 2 5MR11Q/NFL/LN 36/6 Card 200 16° Narrow Flood C8 2900 2000 - 1.8 $0.60 1.38"
10 GU4 04761 2 10MR11Q/NFL/LN 36/6 Card 650 16° Narrow Flood C6 2900 2000 - 1.8 $1.20 1.38"
20 GU4 04748 2 20MR11Q/SP/LN 36/6 Card 700 12° Spot C8 2800 2000 FTB 1.8 $2.41 1.38"
GU4 04750 2 20MR11Q/NFL/LN 36/6 Card 1600 16° Narrow Flood CC6 2950 2000 FTC 1.8 $2.41 1.38"
GU4 06214 2,7 20MR11X/FL/LN 2CD 36/6 Card (2) 700 30° Flood C8 2900 10000 FTD 9.1 $2.41 1.38"
35 GU4 04765 2 35MR11Q/NFL/LN 36/6 Card 2800 16° Narrow Flood C6 3000 2000 FTF 1.8 $4.22 1.38"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
