Westinghouse Lighting - Lamp Catalog

23 / 52

HALOGEN LAMPS
21
5 Rough Service
6 Canadian Standards Association
1 New Item
2 Clear Lens
3 Frost Lens
4 Eco-Halogen Energy-Saving Technology
Footnotes
7 Krypton(K) / Xenon(X)
8 Long Neck
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est. Yearly
Energ
Cost** MOL
JDR 120 VOLT
50 Med. 04753 2 50JDR16Q/FL/LN 36/6 Card 1000 36° Flood CC8 2800 330 2000 1.8 $6.02 3.00"
75 Med. 04731 2 75JDR16Q/NFL/LN 36/6 Card 1350 20° Narrow Flood CC8 2900 630 1500 1.3 $9.03 2.75"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
JDR LAMPS,
120 VOLT (LINE VOLTAGE) JDR MEDIUM BASE
MR16 LAMPS,
120 VOLT DICHROIC (LINE VOLTAGE)
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
MR16 120 VOLT
20 GU7.9/8.0 04521 2 20MR16Q/FL/LN 36/6 Card 200 30° Flood CC2V 3050 85 3000 2.7 $2.41 1.91"
25 GU10 04787 2 25MR16Q/GU10/FL/LN 36/6 Card 300 30° Flood CC2V 3050 140 2000 1.8 $3.01 2.00"
35 GU7.9/8.0 04727 2 35MR16Q/FL/LN 36/6 Card 500 30° Flood CC2V 3050 200 3000 2.7 $4.22 1.91"
GU10 04741 2 35MR16Q/GU10/FL/LN 36/6 Card 500 32° Flood CC2V 2800 180 1500 1.3 $4.22 2.00"
45 GU7.9/8.0 04711 2 45MR16Q/FL/LN 36/6 Card 1800 36° Flood CC2V 3050 270 2000 1.8 $5.42 1.75"
50 GU7.9/8.0 04725 2 50MR16Q/FL/LN 36/6 Card 950 32° Flood CC2V 3050 330 2000 1.8 $6.02 1.75"
GU10 04449 50MR16Q/GU10/FL 100/10 Box 1800 36 Flood CC2V 3050 500 1500 1.3 $6.02 2.00"
GU10 04730 2 50MR16Q/GU10/FL/LN 3CD 12/6 Card (3) 950 32° Flood CC2V 3050 330 2000 1.8 $6.02 2.00"
GU10 04740 2 50MR16Q/GU10/FL/LN 36/6 Card 950 32° Flood CC2V 3050 330 1500 1.3 $6.02 2.00"
GU10 03529 3 50MR16Q/GU10/F/FL/LN 36/6 Card 900 36° Flood CC2V 3050 330 2000 1.8 $6.02 2.00"
GU10 06211 2,7 50MR16X/FL/GU10/LN 2CD 36/6 Card (2) 1100 30° Flood CC2V 3050 500 3500 3.1 $6.02 2.00"
GU10 04747† 1,3 50MR16Q/GU10/F/FL/LNBACKLIT 36/6 Card - - Flood - 2850 500 2000 1.8 $6.02 2.04"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
MR16 GU7.9/8.0 BASE MR16 GU10 BASE MR16 FROST LENS GU10 BASE
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes
Domestic
Code Volts
Master
Carton/
Inner Pack
Package
Type Finish
Filament
Type
Light
Appearance
(Kelvin)
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
T3
5 G4 06240 5T3 12 36/6 Card Clear C8 2800 60 2000 1.8 $0.60 1.31"
10 G4 04442 10T3 12 100/10 Box Clear C6 2900 130 2000 1.8 $1.20 1.19"
G4 04742 10T3 12 36/6 Card Clear C8 2900 120 2000 1.8 $1.20 1.19"
G4 06308 10T3 4CD 12 36/6 Card (4) Clear C6 2900 100 2000 1.8 $1.20 1.19"
G4 06216 7 10T3X 2CD 12 36/6 Card (2) Clear C6 2900 100 5000 4.5 $1.20 1.19"
15 G4 04982 15T3/6V 6 36/6 Card Clear C6 2900 180 2000 1.8 $1.81 1.27"
20 G4 04436 20T3 12 100/10 Box Clear C6 2950 300 2000 1.8 $2.41 1.19"
G4 04736 20T3 12 36/6 Card Clear C8 2950 300 2000 1.8 $2.41 1.19"
G4 04734 20T3/F 12 36/6 Card Frost C8 2950 290 2000 1.8 $2.41 1.19"
G4 06209 7 20T3X 2CD 12 36/6 Card (2) Clear C6 2900 300 10000 9.1 $2.41 1.19"
GY6.35 04444 20T3Q 12 100/10 Box Clear C6 2950 300 2000 1.8 $2.41 1.63"
35 G4 06218 7 35T3X/12V 2CD 12 36/6 Card (2) Clear C6 2900 550 10000 9.1 $4.22 1.19"
GY6.35 04445 35T3Q 12 100/10 Box Clear C6 3050 595 2000 1.8 $4.22 1.63"
50 GY6.35 04438 50T3Q 12 100/10 Box Clear C6 3050 900 2000 1.8 $6.02 1.63"
T4
20 GY6.35 04743 20T4Q 12 36/6 Card Clear C6 2950 300 2000 1.8 $2.41 1.63"
35 GY6.35 04745 35T4Q 12 36/6 Card Clear C6 3000 600 2000 1.8 $4.22 1.63"
50 GY6.35 04738 50T4Q 12 36/6 Card Clear C6 3050 900 2000 1.8 $6.02 1.63"
GY6.35 04735 50T4Q/F 12 36/6 Card Frost C6 3050 870 2000 1.8 $6.02 1.63"
75 GY6.35 04739 75T4Q 12 36/6 Card Clear C6 3050 1350 2000 1.8 $9.03 1.63"
100 GY6.35 04729 100T4Q 12 36/6 Card Clear C6 3050 2100 2000 1.8 $12.05 1.63"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
JC LAMPS (LOW VOLTAGE) JC CLEAR G4 BASE JC CLEAR GY6.35 BASE JC FROST G4 BASE JC FROST GY6.35 BASE
MR16 BACKLIT GU10 BASE
† SPECIALTYMR16 EMITS LIGHT FORWARD AND BACKWARD
