LIGHTING HARDWARE
118
CARDED PRODUCT SOLD IN INNER PACK ONLY.
* Bulk Pack
LIGHTING HARDWARE
Adjustable
All-Purpose Crossbar
70111
Slips 3/8-IP
Holes Tapped 8-32
Adjusts from 37/8" to 5" for
Slot Mounting on 3", 31/4" or 4" Box
Two 1/2" Head Screws Included
Two 1/4" Head Screws Included
35 lb. Load Rating
4" Offset Crossbar
70112
Two 1/2" Mounting Screws
and 2 Tapped 8-32 Holes
Spaced 23/4" Apart
Slips 3/8-IP
35 lb. Load Rating
4" Crossbar Kit
70110
Tapped 1/4-IP
35 lb. Load Rating
Includes:
• 1 Crossbar
• 1 3/8-IP x 1/4-IP Reducing Hickey
• 1 1/4-IP x 1/8-IP Reducing Bushing
• 2 8-32 x 1/2" Mounting Screws
Circular Crossbar
21038
4 Tapped 8-32 Holes
23/4" Center to Center
31/2" Center to Center
45 lb. Load Rating
Crossbar 4" Long
21005
4" Long
Tapped 1/4-IP
45 lb. Load Rating
6 Assorted Nipples
70151
Zinc-Plated
Includes:
• 21/4-IP x 3/4"
• 21/4-IP x 11/2"
• 21/4-IP x 2"
Crossbar 3-7/8" Long
21008
3 " Long
Ground Screw Inserted
Tapped 1/4-IP
45 lb. Load Rating
Crossbar 4" Long
21004
4" Long
Tapped 1/8-IP
Green Ground Screw
45 lb. Load Rating
Phenolic Shade Ring
For Medium Base Sockets
70435
Outside Diameter - 23/16"
Inside Diameter - 15/8"
For use with phenolic sockets only.
Socket Ring Tool
For Medium Base
Threaded Rings
70013
Diameter - 2"
Height - 43/8"
For use with aluminum socket rings.
Steel Shade Ring
For Medium Base Sockets
70428
Ring Size - 23/8"
Outside Diameter - 21/4"
Inside Diameter - 11/2"
2 Aluminum Shade Rings
For Medium Base Sockets
70001
Outside Diameter - 2"
Inside Diameter - 11/2"
For use with porcelain
threaded sockets.
Mogul
Medium
2 Replacement Knobs
70161
Black Finish
With 1/2" Extensions
Tapped 4/36-F x 4/36-M
2 Socket Keys
70160
Brass Finish
With 1/2" Extensions
Tapped 4/36-F x 4/36-M
Fluorescent Lamp Starters
22562 - FS-5
4, 6 and 8 Watt Lamps
Socket
Adapter Reducer
22406
Reduces Mogul Base
to Medium Base
660 Watts Max.
250 Volts
*
Fluorescent Lamp Starters
22560 - FS-2
14, 15 and 20 Watt Lamps
22561 - FS-4
30 and 40 Watt Lamps
*
*
3-Way Canopy Switch
with 4' White Braided Cord
22324 - Nickel Finish
6" Wire Leads, 18 Gauge, 105° Leads
Fits 3/8" Hole
1A, 125 VT, 3A, 250 VAC
6A, 125 VL, 6A, 125 VAC
Sequence of Operation:
Low / Medium / High / Off
Height - 13/16", 250V Maximum
*
Push Canopy
Switch
22306
43/4" Wire Leads
18 Gauge, 105° Leads
Fits 3/8" Hole
3A, 250 VAC
6A, 125 VL
6A, 125 VAC
Height - 11/4"
*
Single Pole Rotary Switch
with Removable Brass Knob
22303 - Brass Knob
6" Wire Leads
18 Gauge, 105° Leads
7/16" Nipple, Fits 3/8" Hole
3A, 250 VAC
6A, 125 VL, 6A, 125 VAC
Height - 11/16"
*
Pull Chain Canopy Switch
with White Braided Cord
22320 - Nickel Finish, 3' Cord
22321 - Brass Finish, 4' Cord
6" Wire Leads
18 Gauge, 105° Leads
Fits 3/8" Hole
3A, 250 VAC, 6A, 125 VAC
6A, 125 VL
Height - 17/16"
*
*
Crossbar 4" Long
21003
70113
Tapped 1/8-IP
45 lb. Load Rating
*
Offset Crossbar 4" Long
21006
70114
Tapped 8-32 Holes
Green Ground Screw
35 lb. Load Rating
*
Screw Collar Loop Kit
70350 - Brass Finish
70352 - Antique Brass Finish
Fits Canopies with a 11/16" Center Hole
Tapped 1/4-IP, 35 lb. Load Rating
Includes: • 1 Crossbar
• 1 Screw Collar Loop • 2 Locknuts
• 1 Lock Washer • 11/4-IP x 11/2" Nipple
• 13/8-IP x 1/4-IP Reducing Hickey
• 2 8-32 x 1/2" Mounting Screws
* * * *
Replacement Canopy
Light Switch with
Brass Finish Pull Chain
70290
3' Braided Cord
6" Wire Leads
Height - 11/4"
Fits 3/8" Hole
