146 / 212
Sidemount Plus Fan Box® Display (18"L x 6
1
/
8
"D x 8"H)
#01240DISP
10-24 threads
for ceiling fans
and chandeliers
8-32 threads for cover
plates and lightweight
lighting fixtures
Saf-T-Cap® to protect bolts
and wires during painting
and sheetrock installation
Mounting hardware
Saf-T-Cap® to protect bolts
and wires during painting and
sheetrock installation
8-32 threads for cover
plates and lightweight
lighting fixtures
Mounting hardware
10-24 threads
for ceiling fans
and chandeliers
Step 1
Mount bracket to joist
through 4" hole in sheetrock.
Step 2
Pull wire into box and remount
box to bracket.
Easy to Install through 4" Hole in Sheetrock
1 Romex clamp
1 Romex clamp
Sidemount
Plus Fan Box®
Ideal for Remodel Applications
• Sidemount bracket is removable for easy replacement of
existing nail-on boxes without attic access
• Fits all ceiling fans
• Includes mounting hardware and instructions
• For fixture support of 70 lbs. or less
• Acceptable for fan support of 70 lbs. or less
01240 & 0124011
Sidemount Plus Fan Box®
3 Knockouts for Conduit or Romex
Box Depth 2
1/8
"
Heavy Duty, 21.5 Cubic Inch
Dual Mount* Electrical Box
01240 Individually Packaged, 4 Per Cut Case
0124011 Bulk Packed, 12 Per Cut Case
01250 & 0125011
Sidemount Plus Fan Box®
3 Knockouts for Conduit or Romex
Box Depth 1
1/2
"
Heavy Duty, 15.5 Cubic Inch
Dual Mount* Electrical Box
01250 Individually Packaged, 24 Per Cut Case
0125011 Bulk Packed, 24 Per Cut Case
85E6
PATENTED
TECHNOLOGY
US PATENT NO.
5,860,548
For more display information, contact your
Westinghouse Sales Representative.
new!
LIGHT FIXTURE AND CEILING FAN ACCESSORIES
www.westinghouselighting.com144
Meets or Exceeds UL Standards Regarding Exposed Threads Within Box. Meets or Exceeds NEC
®
Safety Codes.
*Dual Mount = Box is threaded for 8-32 (ideal for box covers and light weight fixtures) and 10-24 screws (ideal for heavier fixtures and fans).
