For more display information, contact your
Westinghouse Sales Representative.
Saf-T-Brace® Display (18"L x 61/8"D x 8"H)
#01010DISP
new!
Saf-T-Brace®
01010
Saf-T-Brace®
Box Depth 11/2"
Heavy Duty, 15.5 Cubic Inch Dual Mount* Electrical Box
6 Knockouts for Conduit or Romex
Individually Packaged, 24 Per Cut Case
Extra Strong Grip
Four teeth and
single screw
on each end
8-32 threads for
cover plates and lightweight
lighting fixtures
10-24 threads for ceiling fans
and chandeliers
Each end screws
into joist independently
Ideal for Retrofit Application
No Attic Access Required
• Fits 16" to 24" ceiling joists
• Patented design provides fast fingertip expansion and
positive attachment to joists
• Fits all ceiling fans
• Position box anywhere along the brace
• For fixture support of 150 lbs. or less on 16" centers
• For fixture support of 50 lbs. or less on 24" centers
• Acceptable for fan support of 70 lbs. or less
85E6
Saf-T-Cap® to protect
bolts and wires during
painting and
sheetrock installation
Mounting hardware
Romex connector
Includes Mounting Hardware & Instructions
Step 1
Easy installation from
below ceiling through any 4"
diameter hole.
Step 2
Install end “A” by turning unit
clockwise and applying pressure
toward the ceiling joist.
A
Step 3
Slide unit toward other
joist and again apply
clockwise pressure.
Step 4
Attach electrical box and install
fan or lighting fixture per
manufacturer’s instructions.
Additional Security from Screw Connector
PATENTED
TECHNOLOGY
US PATENT NO.
4,909,405
4,659,051
5,860,548
DES.306,254
LIGHT FIXTURE AND CEILING FAN ACCESSORIES
139
Meets or Exceeds UL Standards Regarding Exposed Threads Within Box. Meets or Exceeds NEC® Safety Codes.
*Dual Mount = Box is threaded for 8-32 (ideal for box covers and light weight fixtures) and 10-24 screws (ideal for heavier fixtures and fans).
