CEILING FAN AND LIGHT FIXTURE ACCESSORIES

www.westinghouselighting.com

216

For more display information, contact your

Westinghouse Sales Representative.

Saf-T-Brace® Display (18"L x 6

1

/

8

"D x 8"H)

#01010DISP

01010

Saf-T-Brace®

Box Depth 11/2"

Heavy Duty, 15.5 Cubic Inch Dual Mount* Electrical Box

6 Knockouts for Conduit or Romex

Individually Packaged, 24 Per Cut Case

Extra Strong Grip

Four teeth and

single screw

on each end

8-32 threads for

cover plates and lightweight

lighting fixtures

10-24 threads for ceiling fans

and chandeliers

Each end screws

into joist independently

IDEAL FOR RETROFIT APPLICATION

NO ATTIC ACCESS REQUIRED

• Fits 16" to 24" ceiling joists.

• Provides fast fingertip expansion and

positive attachment to joist.

• Fits all ceiling fans.

• Position box anywhere along the brace.

• For fixture support of 150 lbs. or less on 16" centers.

• For fixture support of 50 lbs. or less on 24" centers.

• Acceptable for fan support of 70 lbs. or less.

85E6

Saf-T-Cap® to protect

bolts and wires during

painting and

sheetrock installation

Mounting hardware

Romex connector

Includes Mounting Hardware & Instructions

Step 1

Easy installation from

below ceiling through any 4"

diameter hole.

Step 2

Install end “A” by turning unit

clockwise and applying pressure

toward the ceiling joist.

Step 3

Slide unit toward other

joist and again apply

clockwise pressure.

Step 4

Attach electrical box and install

fan or lighting fixture per

manufacturer’s instructions.

Additional Security from Screw Connector

Saf-T-Brace®

Meets or Exceeds UL Standards Regarding Exposed Threads Within Box. Meets or Exceeds NEC

®

Safety Codes.

*Dual Mount = Box is threaded for 8-32 (ideal for box covers and light weight fixtures) and 10-24 screws (ideal for heavier fixtures and fans).
