CEILING FAN AND LIGHT FIXTURE ACCESSORIES
www.westinghouselighting.com223
Ceiling fan or
lighting fixture
attaches to structure
support, not to plastic
Clips inside box hold screws
during initial installation
Get the Wiring Space
You Need...
Where You Need It!
Application Illustration
for All Fan Master Products
(Shown with 0200011)
IDEAL FOR NEW CONSTRUCTION APPLICATIONS
• Fits all ceiling fans.
• 2 knockouts for Conduit or Romex.
• Two hour fire rating.
• Includes mounting hardware and instructions.
• For fixture support of 150 lbs. or less.
• Acceptable for fan support of 70 lbs. or less.
0252511
Fan Master Jr.®
Height 4"
Box Depth
1/2
"
13.4 Cubic Inch Wiring Capacity
0252511 Bulk Packed, 12 Per Cut Case
0200011
Fan Master®
Height 4
13/16
"
Box Depth
5/8
"
16.5 Cubic Inch Wiring Capacity
0200011 Bulk Packed, 24 Per Cut Case
5F51
Saf-T-Cap® to protect bolts
and wires during painting
and sheetrock installation
4"
Mounting hardware
Romex connector
Romex clamp
Built-in Tab
Saf-T-Cap® to protect bolts
and wires during painting and
sheetrock installation
Mounting hardware
4
13
⁄
16
"
Romex connector
Romex clamp
Built-in Tab
Built-in tabs allow for easier
hands free installation
Fan Master Jr.® Display (18"L x 6
1
/
8
"D x 8"H)
#02525DISP
For more display information, contact your
Westinghouse Sales Representative.
Fan Master Jr.® & Fan Master®
Meets or Exceeds UL Standards Regarding Exposed Threads Within Box. Meets or Exceeds NEC
®
Safety Codes.
*Dual Mount = Box is threaded for 8-32 (ideal for box covers and light weight fixtures) and 10-24 screws (ideal for heavier fixtures and fans).
