Westinghouse Lighting - Lamp Catalog

39 / 52

Footnotes
3 Not for use with electronic dimmers
4 For use with electronic dimmers and dimming ballasts
1 New Item
2 Approved for Damp Locations
Compact Fluorescent Lamps contain mercury. For more on clean up and safe disposal, visit epa.gov/cfl.Hg
COMPACT FLUORESCENT LAMPS
37
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type
Color
Designation
Light
Appearance
(Kelvin) CRI
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.Yearly
Energy
Cost** MOL
2-PIN (PREHEAT ELECTROMAGNETIC BALLASTS)
5 G23 37040 2,3 F5TT/27 72/6 Box Warm White 2700 82 250 10000 9.1 $0.60 4.31"
7 G23 37041 2,3 F7TT/27 72/6 Box Warm White 2700 82 400 10000 9.1 $0.84 5.38"
G23 37373 2,3 F7TT/27 36/6 Card Warm White 2700 82 400 10000 9.1 $0.84 5.38"
G23 06126 2,3 F7TT/41 72/6 Box Cool White 4100 82 400 10000 9.1 $0.84 5.38"
9 G23 37374 2,3 F9TT/27 36/6 Card Warm White 2700 82 600 10000 9.1 $1.08 6.63"
G23 37042 2,3 F9TT/27 72/6 Box Warm White 2700 82 600 10000 9.1 $1.08 6.63"
G23 06127 2,3 F9TT/41 72/6 Box Cool White 4100 82 600 10000 9.1 $1.08 6.63"
13 GX23 37043 2,3 F13TT/27 72/6 Box Warm White 2700 82 900 10000 9.1 $1.57 7.19"
GX23 37375 2,3 F13TT/27 36/6 Card Warm White 2700 82 900 10000 9.1 $1.57 7.19"
GX23 06118 2,3 F13TT/35 72/6 Box Cool White 3500 82 900 10000 9.1 $1.57 7.19"
GX23 06128 2,3 F13TT/41 72/6 Box Cool White 4100 82 900 10000 9.1 $1.57 7.19"
GX23-2 37376 2,3 F13DTT/27 36/6 Card Warm White 2700 82 860 10000 9.1 $1.57 4.69"
GX23-2 37044 2,3 F13DTT/27 72/6 Box Warm White 2700 82 860 10000 9.1 $1.57 4.69"
GX23-2 06164 2,3 F13DTT/41 72/6 Box Cool White 4100 82 860 10000 9.1 $1.57 4.69"
18 G24d-2 06129 2,3 F18DTT/41 72/6 Box Cool White 4100 82 1250 10000 9.1 $2.17 6.00"
26 G24d-3 06180 2,3 F26DTT/27 72/6 Box Cool White 2700 82 1500 10000 9.1 $3.13 6.81"
G24d-3 06121 2,3 F26DTT/35 72/6 Box Cool White 3500 82 1500 10000 9.1 $3.13 6.81"
G24d-3 06130 2,3 F26DTT/41 72/6 Box Cool White 4100 82 1500 10000 9.1 $3.13 6.81"
4-PIN
13 G24q-1 37059 4 F13DTT/27/4P 72/6 Box Warm White 2700 82 900 10000 9.1 $1.57 5.19"
G24q-1 37159 4 F13DTT/35/4P 72/6 Box Cool White 3500 82 900 10000 9.1 $1.57 5.19"
G24q-1 37559 4 F13DTT/41/4P 72/6 Box Cool White 4100 82 900 10000 9.1 $1.57 5.19"
G24q-1 37619 4 F13S/27 36/6 Box Warm White 2700 82 900 10000 9.1 $1.57 4.00"
18 G24q-2 37046 4 F18DTT/27/4P 50 Box Warm White 2700 82 1200 10000 9.1 $2.17 5.81"
G24q-2 37146 4 F18DTT/35/4P 50 Box Cool White 3500 82 1200 10000 9.1 $2.17 5.81"
G24q-2 37546 4 F18DTT/41/4P 50 Box Cool White 4100 82 1200 10000 9.1 $2.17 5.81"
26 G24q-3 37047 4 F26DTT/27/4P 50 Box Warm White 2700 82 1800 10000 9.1 $3.13 6.50"
G24q-3 37147 4 F26DTT/35/4P 50 Box Cool White 3500 82 1800 10000 9.1 $3.13 6.50"
G24q-3 37547 4 F26DTT/41/4P 50 Box Cool White 4100 82 1800 10000 9.1 $3.13 6.50"
GX24q-3 37045 4 F26TTT/27/4P 50 Box WarmWhite 2700 82 1800 10000 9.1 $3.13 5.19"
GX24q-3 37145 4 F26TTT/35/4P 50 Box Cool White 3500 82 1800 10000 9.1 $3.13 5.19"
GX24q-3 37545 4 F26TTT/41/4P 50 Box Cool White 4100 82 1800 10000 9.1 $3.13 5.19"
32 GX24q-3 37148 4 F32TTT/35/4P 50 Box Cool White 3500 82 2400 10000 9.1 $3.85 5.81"
GX24q-3 37548 4 F32TTT/41/4P 50 Box Cool White 4100 82 2400 10000 9.1 $3.85 5.81"
42 GX24q-4 37149 4 F42TTT/35/4P 50 Box Cool White 3500 82 3200 10000 9.1 $5.06 6.63"
GX24q-4 37549 4 F42TTT/41/4P 50 Box Cool White 4100 82 3200 10000 9.1 $5.06 6.63"
4-PIN TWIN TUBE LONG
40 2G11 07022 4 F40TTL/835 25 Box Cool White 3500 82 3200 20000 18.2 $4.82 22.50"
2G11 07023 4 F40TTL/841 25 Box Cool White 4100 82 3200 20000 18.2 $4.82 22.50"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
PIN BASE
LAMPS
TT (2-PIN)
TWIN TUBE
DTT (2-PIN)
DOUBLE TWIN TUBE
DTT (4-PIN)
DOUBLE TWIN TUBE
TTT (4-PIN)
TRIPLE TWIN TUBE
40W (4-PIN)
TWIN TUBE LONG
13WS (4-PIN)
SPIRAL
