LIGHT FIXTURESLINEAR FLUORESCENT LAMPS
Fluorescent Lamps contain mercury. For more on clean up and safe disposal, visit epa.gov/cfl.Hg
39
3 Energy Saver
4 High Output Outdoor
Footnotes
1 New Item
2 Low Mercury Lighting
5 Canadian Standards Association
6 High Lumen/Long Life
7 Realite™ Full Spectrum
T12
LAMPS
T12
PREHEAT
T12
RAPID START
T12 ECOMAX®
RAPID START
T12 ECOMAX®
RAPID START
T12 ECOMAX®
HIGH OUTPUT
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton
Package
Type Finish
Light
Appearance
(Kelvin) CRI
Avg.
Rated Hours
(3Hrs./Start)
Avg.
Rated Hours
(12Hrs./Start)
Brightness
(Lumens)
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
T12 PREHEAT
20 Med. BiPin 05660 F20T12/CW 15 Sleeve Cool White 4100 62 10000 20000 1200 9.1 $2.41 24"
T12 RAPID START
30 Med. BiPin 07650 F30T12/CW 30 Sleeve Cool White 4100 62 16000 25000 1900 14.6 $3.61 36"
40 Med. BiPin 05752 F40T12/CWX 30 Bulk Cool White Deluxe 4100 89 20000 20000 2600 18.2 $4.82 48"
Med. BiPin 05914 F40T12/CWX 2PK 15 Sleeve (2) Cool White Deluxe 4100 89 20000 20000 2600 18.2 $4.82 48"
Med. BiPin 07523 F40T12/DD 6 Sleeve Daylight Deluxe 6500 90 20000 25000 2200 18.2 $4.82 48"
T12 ECOMAX® RAPID START (REDUCED MERCURY)
40 Med. BiPin 05906 2 F40T12/DD/ES/ECOMAX 30 Bulk Daylight Deluxe 6500 90 20000 20000 2025 18.2 $4.82 48"
75 Single Pin 05903 2 F96T12/DD/ECOMAX 15 Bulk Daylight Deluxe 6500 90 12000 12000 4500 10.9 $9.03 96"
T12 ECOMAX® HIGH OUTPUT (REDUCED MERCURY, 800MA)
110 Rec. D.C. 07910 2,4 F96T12/CW/HO-O/ECOMAX 15 Bulk Cool White 4100 62 12000 12000 8800 10.9 $13.25 96"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
E
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton
Package
Type Finish
Light
Appearance
(Kelvin) CRI
Avg. Rated
Hours
(3Hrs./Start)
Avg. Rated
Hours
(12Hrs./Start)
Brightness
(Lumens)
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
T8 ECOMAX® U-BENT RAPID START LAMP (6" LEG SPACING)
32 Med. BiPin 37317 2 FB32T8/841/6/ECOMAX 20 Box Cool White 4100 84 20000 24000 2800 18.2 $3.85 22.50"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
T8 ECOMAX®
U-BENT LAMP T8 ECOMAX® U-BENT LAMP
Means this bulb meets Federal
minimum e ciency standards E
CIRCULAR LAMPS T6 2C CIRCULAR LAMP T9 CIRCULAR LAMP
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Package
Type Finish
Light
Appearance
(Kelvin) CRI
Avg. Rated
Hours
(3Hrs./Start)
Brightness
(Lumens)
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
T6 2C CIRCULAR (4-PIN)
40 GU10q 37340 FC40/2C/WW 36/6 Box WarmWhite 3000 82 10000 2800 9.1 $4.82 7.50"
T9 CIRCULAR
22 4-Pin 06010 FC8T9/CW 12 Hanging Box Cool White 4100 62 9000 1040 8.2 $2.65 8"
4-Pin 06013 FC8T9/WW 12 Hanging Box WarmWhite 3000 52 9000 1040 8.2 $2.65 8"
32 4-Pin 06020 FC12T9/CW 12 Hanging Box Cool White 4100 62 10000 1940 9.1 $3.85 12"
4-Pin 06023 FC12T9/WW 12 Hanging Box WarmWhite 3000 52 10000 1940 9.1 $3.85 12"
40 4-Pin 06030 FC16T9/CW 6 Hanging Box Cool White 4100 62 10000 2660 9.1 $4.82 16"
*Based on 3hrs./day **Based on operating 3hrs./day 11¢/kWh
Item No. Domestic Code Master Carton/Inner Pack Package Type Finish MOL
T8 (INCLUDES END CAPS)
07946 TUBEGUARD/T8/48 24 Bulk Clear 48"
07944 TUBEGUARD/T8/96 24 Bulk Clear 96"
T12 (INCLUDES END CAPS)
07948 TUBEGUARD/T12/48 12 Bulk Clear 48"
07949 TUBEGUARD/T12/96 12 Bulk Clear 96"
TUBE GUARDS WITH END CAPS
ALL TUBE GUARDS AND END CAPS ARE NOT FOR USE WITH HO LAMPS. TUBE GUARD WITH END CAP
