HID LAMPS
40
HIGH INTENSITY
DISCHARGE (HID) LIGHTING
Our HID lamp line includes pulse start and protected metal halides,
high pressure sodium, and mercury vapor options. These lamps offer increased lamp
efficacy and higher light output than standard incandescent or fluorescent lamps.
HID Lamps contain mercury. For more on clean up and safe disposal, visit epa.gov/cfl.Hg
3 Low Profile
4 Universal Operating Position
Footnotes
1 New Item
2 For Probe Start or Pulse Start Ballasts
5 Specifications based on operating at a base up (BU) position
HIGH PRESSURE
SODIUM LAMPS
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton
Package
Type Finish
Light
Appearance
(Kelvin) CRI
ANSI
Code
Avg.
Rated
Hours
Brightness
(Initial
Lumens)
Brightness
(Mean
Lumens) MOL
ED17
35 Med. 37430 LU35/S76/MED 6 Box Clear 1900 15 S76 24000 2250 2050 5.44"
50 Med. 37432 LU50/S68/MED 6 Box Clear 1900 15 S68 24000 4000 3600 5.44"
70 Med. 37435 LU70/S62/MED 6 Box Clear 1900 15 S62 24000 6300 5520 5.44"
100 Med. 37439 LU100/S54/MED 6 Box Clear 2100 25 S54 24000 9500 8000 5.44"
150 Med. 37442 LU150/S55/MED 6 Box Clear 2100 25 S55 24000 14500 13300 5.44"
ED23 1/2
70 Mogul 37437 LU70/S62 6 Box Clear 1900 15 S62 24000 6300 5500 7.75"
100 Mogul 37440 LU100/S54 6 Box Clear 2100 25 S54 24000 9500 8000 7.75"
150 Mogul 37443 LU150/S55 6 Box Clear 1900 25 S55 24000 14500 11600 7.75"
ET18
250 Mogul 37444 LU250/S50 6 Box Clear 1900 21 S50 24000 27500 22000 9.75"
400 Mogul 37445 LU400/S51 6 Box Clear 2100 21 S51 24000 50000 40000 9.75"
ET25
1000 Mogul 37447 LU1000/S52 12 Box Clear 2100 21 S52 24000 130000 120700 15.13"
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton
Package
Type Finish
Light
Appearance
(Kelvin) CRI
ANSI
Code
Avg.
Rated
Hours
Brightness
(Initial
Lumens)
Brightness
(Mean
Lumens) MOL
E17
100 Med. 37404 HF100XR/H38/MED 6 Box White 4000 41 H38 24000 4500 3600 5.44"
ED23 1/2
100 Mogul 37403 HF100XR/H38 6 Box White 4000 41 H38 24000 4500 3600 8.25"
BT28
175 Mogul 37405 HF175XR/H39 6 Box White 4000 41 H39 24000 8900 7120 8.31"
Mogul 37002 HF175XR/H39/CL 6 Box Clear 6800 20 H39 10000 7800 6630 8.25"
BT37
400 Mogul 37407 HF400XR/H33 6 Box White 4000 41 H33 24000 24000 19200 11.50"
MERCURY
VAPOR LAMPS
ED23 1/2
BT37
ET18 ET25 ED17
BT28 E17 ED23 1/2 BT28
