Westinghouse Lighting - Lamp Catalog

52 / 84

MR16, 12 VOLT, DICHROIC (LOW VOLTAGE)
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Pack
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Avg.
Rated
Hours
ANSI
Code
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
20 GU5.3 04451 20MR16Q/FL 100/10 Box 460 36° Flood C8 2950 2000 BAB 1.8 $2.41 1.81"
GU5.3 04581 20MR16Q/FL 100/10 Box 460 38° Flood C8 2950 5000 BAB 4.5 $2.41 1.88"
GU5.3 04781 2 20MR16Q/FL/LN 36/6 Card 600 32° Flood C8 2950 2000 BAB 1.8 $2.41 1.81"
GU5.3 06212 2,7 20MR16X/FL/LN 2CD 36/6 Card(2) 700 32° Flood C8 2950 10000 BAB 9.1 $2.41 1.81"
GU5.3 04450 20MR16Q/SP 100/10 Box 3300 12° Spot C8 2950 2000 ESX 1.8 $2.41 1.81"
GU5.3 04749 2 20MR16Q/SP/LN 36/6 Card 3500 12° Spot C8 2950 2000 ESX 1.8 $2.41 1.81"
35 GU5.3 04562 35MR16Q/FL 100/10 Box 1500 38° Flood C8 3000 5000 FMW 4.5 $4.22 1.88"
GU5.3 04563 35MR16Q/FL/LN 36/6 Card 1250 32° Flood C8 3000 2000 FMW 1.8 $4.22 1.81"
50 GU5.3 04455 50MR16Q/NFL 100/10 Box 3000 20° Narrow Flood C8 3050 2000 EXZ 1.8 $6.02 1.81"
GU5.3 04755 2 50MR16Q/NFL/LN 36/6 Card 4300 18° Narrow Flood C6 3050 2000 EXZ 1.8 $6.02 1.81"
GU5.3 04456 50MR16Q/FL 100/10 Box 1500 38° Flood C8 3050 2000 EXN 1.8 $6.02 1.81"
GU5.3 04556 2 50MR16Q/FL/LN 100/10 Box 1500 38° Flood C8 3050 2000 EXN 1.8 $6.02 1.81"
GU5.3 04586 50MR16Q/FL 100/10 Box 2000 38° Flood C8 3000 5000 EXN 4.5 $6.02 1.88"
GU5.3 04756 2 50MR16Q/FL/LN 36/6 Card 1650 32° Flood C8 3050 2000 EXN 1.8 $6.02 1.81"
GU5.3 05201 3,6 50MR16Q/F/FL/LN 36/6 Card 1550 49° Flood C6 2950 4000 EXN 3.6 $6.02 1.81"
GU5.3 06213 2,7 50MR16X/FL/LN 2CD 36/6 Card(2) 1500 32° Flood C8 3050 10000 EXN 9.1 $6.02 1.81"
GU5.3 04454 50MR16Q/SP 100/10 Box 9150 12° Spot C8 3050 2000 EXT 1.8 $6.02 1.81"
GU5.3 04559 2 50MR16Q/SP/LN 36/6 Card 10000 12° Spot C8 3050 2000 EXT 1.8 $6.02 1.81"
75 GU5.3 04458 75MR16Q/FL 100/10 Box 2000 38° Flood C8 3050 2000 EYC 1.8 $9.03 1.81"
GU5.3 04758 2 75MR16Q/FL/LN 36/6 Card 2940 32° Flood C8 3050 2000 EYC 1.8 $9.03 1.81"
MR11, 120 VOLT DICHROIC (LINE VOLTAGE)
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Pack
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Avg.
Rated
Hours
ANSI
Code
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
35 GU10 04728 1 35MR11Q/GU10/NFL/LN 3CD 36/6 Card(3) 500 30° Narrow Flood CC2V 3000 3000 FTH 2.7 $4.22 1.38"
* Based on 3 hrs./day ** Based on 3 hrs./day 11¢/kWh — Cost depends on rates and use.
MR11, DICHROIC (LOW VOLTAGE)
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Pack
Type
Candle
Power
Beam
Spread
Beam
Type
Filament
Type
Light
Appearance
(Kelvin)
Avg.
Rated
Hours
ANSI
Code
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
6 VOLT
5 GU4 04771 2 5MR11Q/NFL/LN 36/6 Card 200 16° Narrow Flood C8 2900 2000 – 1.8 $0.60 1.38"
12 VOLT
5 GU4 04766 2 5MR11Q/NFL/LN 36/6 Card 200 16° Narrow Flood C8 2900 2000 – 1.8 $0.60 1.38"
10 GU4 04761 2 10MR11Q/NFL/LN 36/6 Card 650 16° Narrow Flood C6 2900 2000 – 1.8 $1.20 1.38"
20 GU4 04463 20MR11Q/NFL 100/10 Box 1500 16° Narrow Flood C8 2950 2000 FTC 1.8 $2.41 1.38"
GU4 04750 2 20MR11Q/NFL/LN 36/6 Card 1600 16° Narrow Flood CC6 2950 2000 FTC 1.8 $2.41 1.38"
GU4 06214 2,7 20MR11X/FL/LN 2CD 36/6 Card(2) 700 30° Flood C8 2900 10000 FTD 9.1 $2.41 1.38"
GU4 04748 2 20MR11Q/SP/LN 36/6 Card 700 12° Spot CC2V 2800 2000 FTB 1.8 $2.41 1.38"
35 GU4 04765 2 35MR11Q/NFL/LN 36/6 Card 2800 16° Narrow Flood C6 3000 2000 FTF 1.8 $4.22 1.38"
MR16 GU5.3 BASE
CLEAR LENS
MR16 FROST LENS
GU5.3 BASE
MR16
GU5.3 BASE
MR11
GU4 BASE
MR11
GU10 BASE
50
HALOGEN LAMPS
7 Krypton(K) / Xenon(X)
8 Long Neck
1 New Item
2 Clear Lens
3 Frost Lens
4 Eco-Halogen Energy-Saving Technology
5 Rough Service
6 Canadian Standards Association
Footnotes
