Westinghouse Lighting - Lamp Catalog

55 / 84

JCD
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code Volts
Master
Carton/
Inner
Pack
Pack
Type Finish
Filament
Type
Light
Appearance
(Kelvin)
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
20 GY7.9/8.0 04710 20T4Q/GY8/120 120 36/6 Card Clear CC2V 2700 200 1500 1.3 $2.41 1.69"
G8 06210 7 20T4X/G8/120 2CD 120 36/6 Card Clear CC2V-H 2700 175 5000 4.5 $2.41 1.38"
25 GY6.35 04715 25T4Q/120 120 36/6 Card Clear CC8 2850 255 1500 1.3 $3.01 1.81"
GY7.9/8.0 04721 25T4Q/GY8/120 120 36/6 Card Clear CC2V 2850 255 1500 1.3 $3.01 1.69"
35 GY6.35 04031 35T4Q/120 120 36/6 Card Clear CC2V 2900 380 1500 1.3 $4.22 1.81"
GY6.35 04431 35T4Q/120 120 100/10 Box Clear CC2V 2900 420 1500 1.3 $4.22 1.81"
GY7.9/8.0 04722 35T4Q/GY8/120 120 36/6 Card Clear CC8 2900 380 1500 1.3 $4.22 1.69"
GY8.6 04712 35T4Q/GY86/120 120 36/6 Card Clear CC8 2900 380 1500 1.3 $4.22 2.25"
50 GY6.35 04417 50T4Q/120 120 100/10 Box Clear CC2V 2900 800 1500 1.3 $6.02 1.81"
GY6.35 04717 50T4Q/120 120 36/6 Card Clear CC2V 2900 600 1500 1.3 $6.02 1.81"
G8 04889 50T4Q/G8/120 120 36/6 Card Clear CC8 2900 600 1500 1.3 $6.02 2.25"
GY8.6 04726 1 50T4Q/GY86/120 120 36/6 Card Clear CC8 2900 600 2000 1.8 $6.02 2.25"
75 GY6.35 04718 75T4Q/120 120 36/6 Card Clear CC8 2900 1050 1500 1.3 $9.03 2.25"
GY8.6 04714 75T4Q/GY86/120 120 36/6 Card Clear CC8 2900 1050 1500 1.3 $9.03 2.25"
GY7.9/8.0 04764 75T4Q/GY8/130 130 36/6 Card Clear CC8 2800 975 2000 1.8 $9.03 2.25"
100 GY6.35 04719 100T4Q/120 120 36/6 Card Clear CC8 2900 1500 1500 1.3 $12.05 2.25"
GY7.9/8.0 04772 1 100T4Q/GY8/120 120 36/6 Card Clear CC8 2850 1500 2000 1.8 $12.05 2.25"
GY8.6 04713 100T4Q/GY86/120 120 36/6 Card Clear CC8 2900 1500 1500 1.3 $12.05 2.25"
GY7.9/8.0 04770 100T4Q/GY8/130 130 36/6 Card Clear CC8 2850 1400 2000 1.8 $12.05 2.25"
G9, 120 VOLT (LINE VOLTAGE)
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner
Pack
Pack
Type Finish
Filament
Type
Light
Appearance
(Kelvin)
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
25 G9 04870 25T4Q/G9/120 36/6 Card Clear CC2V 2800 255 2000 1.8 $3.01 1.69"
35 G9 04872 1 35T4Q/G9/120 36/6 Card Clear CC2V 2800 400 2000 1.8 $4.22 1.69"
40 G9 04901 40T4Q/G9/120 100/10 Box Clear CC2V 2800 480 2000 1.8 $4.82 1.69"
G9 04871 40T4Q/G9/120 36/6 Card Clear CC2V 2800 480 2000 1.8 $4.82 1.69"
G9 04873 1 40T4Q/G9/120 3CD 36/6 Card(3) Clear CC2V 2800 480 2000 1.8 $4.82 1.69"
G9 04703 40T4Q/G9/F/120 100/10 Box Frost CC2V 2800 440 2000 1.8 $4.82 1.69"
G9 04855 40T4Q/G9/F/120 36/6 Card Frost CC2V 2800 460 2000 1.8 $4.82 1.69"
60 G9 04879 60T4Q/G9/120 36/6 Card Clear CC2V 2800 800 2000 1.8 $7.23 1.69"
JCD
GY7.9/8.0 BASE
JCD
GY6.35 BASE
JCD
GY8.6 BASE G9 CLEAR G9 FROST
* Based on 3 hrs./day ** Based on 3 hrs./day 11¢/kWh — Cost depends on rates and use.
JCD
G8 BASE
HALOGEN LAMPS
53
7 Krypton(K) / Xenon(X)
8 Long Neck
1 New Item
2 Clear Lens
3 Frost Lens
4 Eco-Halogen Energy-Saving Technology
5 Rough Service
6 Canadian Standards Association
Footnotes
