Westinghouse Lighting - Lamp Catalog

57 / 84

SINGLE-ENDED, D.C. BAYONET & E11 BASE
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code Volts
Master
Carton/
Inner
Pack
Pack
Type Finish
Filament
Type
Light
Appearance
(Kelvin)
Brightness
(Lumens)
Avg.
Rated
Hours
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
D.C. BAYONET BASE
35 D.C. Bay. 04412 35Q/DC 120 36/6 Card Clear CC2V 2900 380 1500 1.3 $4.22 1.88"
50 D.C. Bay. 04835 50Q/DC 120 36/6 Card Clear CC2V 2900 600 1500 1.3 $6.02 1.88"
D.C. Bay. 04836 50Q/DC 120 100/10 Box Clear CC2V 2900 600 1500 1.3 $6.02 1.88"
75 D.C. Bay. 06246 75Q/DC 120 36/6 Card Clear CC8 2800 975 2000 1.8 $9.03 2.38"
D.C. Bay. 04837 75Q/DC 120 100/10 Box Clear CC2V 2900 975 1500 1.3 $9.03 2.38"
100 D.C. Bay. 04746 100Q/DC 120 36/6 Card Clear CC8 2950 1500 1500 1.3 $12.05 2.38"
D.C. Bay. 04846 100Q/DC 120 100/10 Box Clear CC8 2950 1400 1500 1.3 $12.05 2.38"
150 D.C. Bay. 04847 150Q/DC 120 100/10 Box Clear CC8 3000 2250 1500 1.3 $18.07 2.38"
E11
50 E11 04423 50T4Q/E11 120 100/10 Box Clear CC2V 2900 600 1300 1.1 $6.02 2.25"
E11 04723 50T4Q/E11 120 36/6 Card Clear CC2V 2900 600 1300 1.1 $6.02 2.25"
75 E11 04416 75T4Q/E11 120 100/10 Box Clear CC8 2900 1450 1300 1.1 $9.03 2.5"
E11 04716 75T4Q/E11 120 36/6 Card Clear CC8 2900 1050 1450 1.3 $9.03 2.5"
E11 04706 75T4Q/F/E11 120 36/6 Card Frost CC8 2900 1050 1300 1.1 $9.03 2.5"
100 E11 04983 1 100T4Q/E11/12V 12 36/6 Card Clear C8 2900 1200 2000 1.8 $12.05 2.69"
E11 04467 100T4Q/E11 120 100/10 Box Clear CC8 2950 1900 1300 1.1 $12.05 2.69"
E11 04767 100T4Q/E11 120 36/6 Card Clear CC8 2950 1500 1300 1.1 $12.05 2.69"
150 E11 04468 150T4Q/E11 120 100/10 Box Clear CC8 3000 3300 1300 1.1 $18.07 2.69"
E11 04768 150T4Q/E11 120 36/6 Card Clear CC8 3000 2500 1300 1.1 $18.07 2.69"
250 E11 04469 250T4Q/E11 120 100/10 Box Clear CC8 3050 4000 1300 1.1 $30.11 2.69"
E11 04769 250T4Q/E11 120 36/6 Card Clear CC8 3050 4250 1300 1.1 $30.11 2.69"
500 E11 04470 500T4Q/E11 120 100/10 Box Clear CC8 3100 9000 2000 1.8 $60.23 3.5"
E11 04762 1 500T4Q/E11 120 36/6 Card Clear CC8 3000 9000 2000 1.8 $60.23 3.5"
SINGLE-ENDED XENON / KRYPTON
Energy
Used
(Watts)
Lamp
Base
Item
No. Footnotes Domestic Code Volts
Master
Carton/
Inner
Pack
Pack
Type Finish
Filament
Type
Avg.
Rated
Hours
Brightness
(Lumens)
Life
in
Years*
Est.
Yearly
Energy
Cost** MOL
20 E11 06256 7 20T3/KX/E11 120 100/10 Box Clear CC8 2000 200 1.8 $2.41 2.5"
Cand. 06250 7 20T3/KX/E12 120 100/10 Box Clear CC8 2000 200 1.8 $2.41 2.5"
Cand. 06253 7 20T3/KX/F/E12 120 100/10 Box Frost CC8 2000 190 1.8 $2.41 2.5"
40 E11 06257 7 40T3/KX/E11 120 100/10 Box Clear CC8 2000 560 1.8 $4.82 2.5"
E11 06243 7 40T3/KX/E11 120 36/6 Card Clear CC8 2000 560 1.8 $4.82 2.5"
Cand. 06251 7 40T3/KX/E12 120 100/10 Box Clear CC8 2000 560 1.8 $4.82 2.5"
Cand. 06244 7 40T3/KX/E12 120 36/6 Card Clear CC8 2000 560 1.8 $4.82 2.5"
Cand. 06254 7 40T3/KX/F/E12 120 100/10 Box Frost CC8 2000 540 1.8 $4.82 2.5"
60 E11 06258 7 60T3/KX/E11 120 100/10 Box Clear CC8 2000 960 1.8 $7.23 2.5"
Cand. 06252 7 60T3/KX/E12 120 100/10 Box Clear CC8 2000 960 1.8 $7.23 2.5"
Cand. 06245 7 60T3/KX/E12 120 36/6 Card Clear CC8 2000 960 1.8 $7.23 2.5"
Cand. 06255 7 60T3/KX/F/E12 120 100/10 Box Frost CC8 2000 950 1.8 $7.23 2.5"
* Based on 3 hrs./day ** Based on 3 hrs./day 11¢/kWh — Cost depends on rates and use.
SINGLE-ENDED
D.C. BAYONET BASE
SINGLE-ENDED
E11 BASE
T3 XENON/KRYPTON
CANDELABRA BASE
T3 XENON/KRYPTON
E11 BASE
CLEAR FROST CLEAR FROST CLEAR FROST CLEAR
HALOGEN LAMPS
55
7 Krypton(K) / Xenon(X)
8 Long Neck
1 New Item
2 Clear Lens
3 Frost Lens
4 Eco-Halogen Energy-Saving Technology
5 Rough Service
6 Canadian Standards Association
Footnotes
