Contains mercury. For more on clean up and safe disposal, visit epa.gov/cfl.Hg
T5 LAMPS
Energy
Used
(Watts) Lamp Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Pack
Type
Light
Appearance
(Kelvin) CRI
Avg. Rated
Hours
(3 Hrs./Start)
Avg. Rated
Hours
(12 Hrs./Start)
Brightness
(Lumens)
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
T5 MINIATURE
6 Mini BiPin 07380 F6T5/CW 72/12 Sleeve 4100 62 5000 9000 270 4.5 $0.72 9"
8 Mini BiPin 04044 F8T5/CW 6 Hanging Box 4100 62 5000 9000 380 4.5 $0.96 12"
Mini BiPin 07440 F8T5/CW 72/12 Sleeve 4100 62 5000 9000 380 4.5 $0.96 12"
Mini BiPin 07443 F8T5/WW 72/12 Sleeve 3000 50 5000 9000 380 4.5 $0.96 12"
13 Mini BiPin 07500 F13T5/CW 72/12 Sleeve 4100 62 5000 10000 860 4.5 $1.57 21"
T5 QUINTALUX™ (REDUCED MERCURY)
28 Mini BiPin 07004 1 F28T5/835 24/6 Sleeve 3500 83 20000 35000 2900 18.2 $3.37 46"
Mini BiPin 07005 1 F28T5/841 24/6 Sleeve 4100 84 20000 35000 2900 18.2 $3.37 46"
54 Mini BiPin 07007 1 F54T5/835/HO 24/6 Sleeve 3500 80 20000 35000 5000 18.2 $6.50 46"
Mini BiPin 07008 1,5 F54T5/841/HO 24/6 Sleeve 4100 81 20000 35000 5000 18.2 $6.50 46"
Mini BiPin 07032 1,5 F54T5/850/HO 24/6 Sleeve 5000 83 20000 35000 4800 18.2 $6.50 46"
* Based on 3 hrs./day ** Based on 3 hrs./day 11¢/kWh — Cost depends on rates and use.
T8 LAMPS
Energy
Used
(Watts) Lamp Base
Item
No. Footnotes Domestic Code
Master
Carton/
Inner Pack
Pack
Type
Light
Appearance
(Kelvin) CRI
Avg. Rated
Hours
(3 Hrs./Start)
Avg. Rated
Hours
(12 Hrs./Start)
Brightness
(Lumens)
Life
in
Years*
Est. Yearly
Energy
Cost** MOL
T8 PREHEAT
15 Med. BiPin 07540 F15T8/CW 72/12 Sleeve 4100 62 7500 12000 850 6.8 $1.81 18"
Med. BiPin 36515 2 F15T8/FS 6 Sleeve 6500 94 8000 10000 700 7.3 $1.81 18"
T8 ECOMAX® (REDUCED MERCURY)
17 Med. BiPin 07445† 1 F17T8/735/ECOMAX 25 Sleeve 3500 75 24000 30000 1325 18.2 $2.05 24"
Med. BiPin 07446† 1 F17T8/741/ECOMAX 25 Sleeve 4100 75 24000 30000 1325 18.2 $2.05 24"
Med. BiPin 07451† 1 F17T8/841/ECOMAX 25 Sleeve 4100 85 24000 30000 1400 18.2 $2.05 24"
25 Med. BiPin 07454 1 F25T8/741/ECOMAX 25 Sleeve 4100 75 24000 30000 2125 18.2 $3.01 36"
Med. BiPin 07456 1 F25T8/835/ECOMAX 25 Sleeve 3500 85 24000 30000 2250 18.2 $3.01 36"
25 Med. BiPin 36012† 1 F25T8/841/ECO/LL 25 Sleeve 4100 84 24000 30000 2500 21.9 $3.01 48"
28 Med. BiPin 36015† 1 F28T8/841/ECO/LL 25 Sleeve 4100 85 24000 30000 2725 21.9 $3.37 48"
Med. BiPin 36016 † 1 F28T8/850/ECO/LL 25 Sleeve 5000 86 24000 30000 2725 21.9 $3.37 48"
32 Med. BiPin 37324† 1 F32T8/830/ECOMAX 25 Sleeve 3000 83 24000 30000 3050 21.9 $3.85 48"
Med. BiPin 37411† 1 F32T8/835/ECOMAX 25 Sleeve 3500 82 24000 30000 3000 21.9 $3.85 48"
Med. BiPin 37413† 1 F32T8/841/ECOMAX 25 Sleeve 4100 84 24000 30000 2950 21.9 $3.85 48"
Med. BiPin 37307† 1 F32T8/850/ECOMAX 25 Sleeve 5000 82 24000 30000 2900 21.9 $3.85 48"
Med. BiPin 07028† 1,6 F32T8/835/XL/ECOMAX 25 Sleeve 3500 84 24000 30000 3100 21.9 $3.85 48"
Med. BiPin 07029† 1,6 F32T8/841/XL/ECOMAX 25 Sleeve 4100 83 24000 30000 3100 21.9 $3.85 48"
T5 MINIATURE T8 PREHEAT T5 QUINTALUX™ T8 ECOMAX®
MEDIUM BIPIN
†Rated Hours for Programmed Rapid Start Ballast is 30,000 at 3 Hours and 36,000 at 12 Hours.
Footnotes
1 Low Mercury Lighting
2 Realite™ Full Spectrum
3 Energy Saver
4 High Output Outdoor
5 Canadian Standards Association
6 High Lumen/Long Life
LINEAR FLUORESCENT LAMPS
